WhisperKOOL 12000 Ceiling Mount Twin Wine Cellar Cooling System

Dimensions:

Dual Evaporators: 35.75"L x 14.5"W x 12.75"H
Condenser: 31.18"L x 10.75"W x 23.25"H

Insulated Line Set:

3/4”Suction (7/8" if greater than 50ft)

3/8”Liquid

Drainline: 1/2” ID clear plastic tubing

Cellar Size: Approx. 3500 Cu.Ft

The Split System does NOT come with its own line set.

Split Systems “split” the cooling system in two, with the evaporator inside the cellar and the condenser being placed nearby.  Placing the condenser in a remote location keeps the wine cellar quiet and vibration-free.

Technicians and installers will be happy to hear that the electrical wiring, bottle probe wiring, and the line set are all located at the bottom of the unit, rather than the top. Not only are the essential components relocated and easier to access, flare fittings will now be utilized so that there is no brazing needed in the field. The redesign includes e-coated duramax evaporator coils which will improve system performance, and a new looking hex mesh grille with an air filter to protect the unit from the intake of potentially harmful debris during the initial start-up.

24Volt+

For the Split System series, a 24V option is also available which allows you to tie into your home electronic thermostat or home automation system, please inquire.

 Although the cooling units are rated for various size rooms, the thermal load may require a larger sized cooling unit.  Thermal load may be affected by glass in the cellar, room positioning or other factors.  Please let a Rosehill Wine Cellar rep make some suggestions for you if needed.
